Doehler & Haass

DH05C

Typ	Loco Decoder
Artnr	DH05C-0 DH05C-1 DH05C-3
Productid	52
Producedfrom	2012
Maße	13.2 x 6.8 x 1.4 mm
Maxtotalcurrent	0.50 A
Maxmotorcurrent	0.50 A
Maxvolts	18 V
Optionen	Analog DC
Connector	Pad Cable NEM651 NEM652 + Cable classicSUSI-Pads
Productlink	Klick

Description:

Operation can be controlled either by conventional DC command stations or by digital central units supporting the formats SelecTRIX 1 and 2, NMRA-Norm (DCC) or MM1/MM2-Standard
Automatic switchover between conventional DC and digital operation
In case of digital operation the last programmed system will be activated (no automatically switchover!)
SelecTRIX 1  31 speed steps, 100 addresses
SelecTRIX 2  127 speed steps, 10.000 addresses, 16 additional functions
DCC  Short addresses (1-127), long addresses (0001-9999), with 14, 28, 126 speed steps
